Density meter Excellence D5

Density meter Excellence D5

Product Details:


Product Description

Product Specifications :

Measurement range (g/cm3)

0 g/cm3 3 g/cm3

Accuracy + (g/cm3)

0.00005 g/cm3

Repeatability (g/cm3)

0.000005 g/cm3

Resolution (g/cm3)

0.00001 g/cm3

Temperature control range

0 oC - 95oC

Temperature control


Measurement scales

Density, Specific gravity, Alcohol, Acid, API, Sugar, Urea, User-defined concentration; Up to 30 user-defined concentration tables (can be entered as tables or formulas).

Minimum sample volume

1.50 mL (1.5 mL)

Integrated drying pump


Video view


Integrated pressure sensor


Automatic sample detection


Clean check


Automatic bubble detection (BubbleCheck)


Automatic viscosity correction


Color-coded result identification


On-screen help texts


User management


Barcode reader connectivity



English; Italian; French; Russian; Polish; Portuguese; Chinese; Korean; German; Spanish

Display / User interface

7" display with color touchscreen


HDMI (Terminal); USB client (PC Software); Ethernet (Network and PC Software); 3 USB host (printer, memory stick, barcode reader, hub, keyboard, mouse); RS232 (Automation units); CAN (Multiple LevelSens)

PC Software

LabX Express and Server

Dimensions (Width x Height x Depth)

267 x 226 x 256 mm


17.5 kg

Standard compliance


Accuracy valid under ideal conditions and for samples with low densities and viscosities

User Management


Product Type

Benchtop Density Meter

Norms and Standards

Ph. Eur. 2.2.5; DIN EN ISO 3675; ISO 2811-3; AOAC Official Method 988.06; AOAC Official Methods of Analysis 950.28, 982.10 (17th Ed); IP 200/52; GBT 11540-2008; ASTM D 4806; API Std 2540; ASTM D 1475; USP chapter 841 (as of USP 29); GB/T 2013-2010; European Union Spirits drinks: COMMISSION REGULATION (EC) No 2870/2000; European Union Wines: COMMISSION REGULATION (EC) No 128/2004; ISO 18301; European Union Wines: COMMISSION REGULATION (EEC) No 2676/90; EN 14214:2003; OIV MA-BS-04 and/or MA-BS-04OIV MA-BS-06 and/or MA-BS-06; ASTM D 2501; ASTM D 6448; ASTM D 1250; ASBC Beer-2; ASBC Beer-5; DIN 51757; Chinese pharmacopoeia 0601; GB/T 13531.4-2013; ISO/EN 15212-1; ISO 12185-2; Pharm. Eu. (2005) JP (2005) USP (2006); AOAC Official Methods of Analysis 920.57, 920.62 (17th Ed); IP 365; ASTM D 5002; ISO 91; ANSI 1250; GB5009.225-2016; ASTM D 4052; OIV Analysis method for density measurement in wine and musts; ASTM D5931; OIV MA-BS-03 and/or MA-BS-03; JJF1070-2005; OIV Alcohol content in wine and musts

LIMS connectivity


Automation for Enhanced Workflow

Autosampler (up to 303 samples); Multiparameter (refractive index, color, pH, etc); Sampling and cleaning (1 sample)

Compliance / Data Security

Audit Trail (requires LabX software); Data integrity (requires LabX software); 21 CFR part 11 / EU Annex 11 (requires LabX software)

Built-in Measurement Scales

Density / Specific gravity; Alcohol tables; Acids / bases and chemical tables; User programmable tables / functions; Brix / Sugar tables

Material Number(s)
