Microbial Detection Analyzer 7000RMS

Operating Range (Temp.)

0 ^oC ; 37 ^oC

Operating Range (Humidity)

10 % ; 90 %

Flow Rate

30 mL/min ; 100 mL/min

Dimensions (HxD)

616 mm x 305 mm

Dimensions (Width)

564 mm

Analysis Time

Continuous

Wall Mount

Anti-vibration shelf required (P/N 58 079 700)

Detection limit

2 AFU (Auto Fluorescent Units)

Minimum detection size

> 0.3 m

Inlet pressure

Process pressure above 80 psig (5.5 bar(g)) requires optional High Pressure Regulator (P/N 58 091 552); 21 - 80 psig (2 - 5.5 bar(g)); Calibration, cleaning and grab sample requires sample pressure of 0 psig (0 bar(g)

Humidity (non-condensing)

80% maximum relative humidity up to 31 ^oC (87.8 ^oF) decreasing linearly to 50% relative humidity at 40 ^oC (104 ^oF)

Ambient temperature (non-condensing)

1 - 37 ^oC (32 - 98.6 ^oF); Temperature below 15 ^oC or above 45 ^oC requires Sample Conditioning Coil (included)

Voltage

TRANSIENT OVER VOLTAGES: up to levels of OVER VOLTAGE CATEGORY II; MAINS supply voltage fluctuations up to +10% of the nominal voltage of 100 - 240 VAC 50 - 60 Hz; TEMPORARY OVER VOLTAGES occurring on the MAINS SUPPLY

Data communication

Analog output channels; Ethernet - standard RJ 45 / Wi-Fi capable; SCADA connectivity via Modbus TCP; USB; 5 - 20 mA standard, with configurable output ranges

Enclosure Material

Stainless Steel

Response Time (Text)

3 seconds (1 mL)

Measurement Range

1 -10,000 AFU / mL

Physical dimensions

(WxHxD) 22.2"(56.4 cm) W x 24.25"(61.6 cm) H x 12"(30.5 cm) D

Monitoring location

At-line to drain

Flow rate

31 mL/min

Use

Indoor use

Environmental Temperature

6 - 35 ^oC (41- 95 ^oF)

Weight (2)

73.4 lbs (33.3 kg)

Outlet connection

0.125" (3 mm) O.D.

Inlet connection

0.125" (3 mm) O.D.

Power Requirements

100 - 240 VAC 50 - 60 Hz 5A; Use the power cord included with the instrument; 8.2' (2.5 m) cord length provided standard

Temperature (non-condensing)

6 - 90 ^oC (41-194 ^oF) Temperature below 15 ^oC or above 45 ^oC requires Sample Conditioning Coil (included)

Environment

Pollution degree 3

Type / Quality

Purified Water (PW), Ultrapure Water (UPW), Water for Injection (WFI)

Altitude

Up to 6562' (2000 m)

Material Number(s)

58045001
