TLD870 Static Pallet Dimensioner

TLD870 Static Pallet Dimensioner

Product Details:


Product Description

Pallets and other large objects can have their weight and dimensions measured with the TLD870 Static Pallet Dimensioner. It is frequently applied in logistics and warehousing operations where precise and effective measuring of goods is crucial for shipment and inventory management.

The TLD870 correctly measures the pallet's length, breadth, and height as well as the weight of the pallet and its contents using cutting-edge laser scanning technology. Following the measurements, the weight and volume of the pallet are calculated in order to choose the most economical and effective shipping strategy.

The TLD870's accuracy and speed are two of its key features. It can quickly and accurately measure a pallet, giving measurements that are typically within 1% of the pallet's actual dimensions and weight. In the process of measuring and shipping, this can increase efficiency and decrease errors.

The simplicity of usage of the TLD870 is another benefit. Its user-friendly interface is designed to be simple and straightforward so that warehouse and logistics employees may use it with little to no training.

The TLD870 Static Pallet Dimensioner is a strong tool for warehousing and logistics organisations aiming to increase the effectiveness and precision of their inventory management and shipping procedures.


Specifications :-TLD870 Static Pallet Dimensioner

Dimensional accuracy (LxWxH)

MID: + 10x10x10 mm, NTEP: Objects up to 72x72x72 in: d = 0.25 in, objects above 72x72x72 in: d = 0.5 in

Max. LFT Size (LxWxH)

MID: 2500x2500x2600 mm, NTEP: 98x98x102 in

Min. LFT Size (LxWxH)

MID: 200x200x100 mm, NTEP: 12x8x3 in


Approx. 240 pallets per hour

Object shape

All solid shapes

Object surface

Most surfaces, including black


Most stable surface down within defined field of view


Flat, continuous surface


Objects are placed under the dimensioner one by one

Light Source

Laser diode, red, wavelength 660 nm


Class II (2)



Material Number(s)
