Refractive Index Cell RX5

Measurement range nD

1.32000 - 1.58000

Accuracy nD (+)

0.00002

Repeatability nD (+)

1e-005

Measurement range Brix

0-100 % w/w

Accuracy Brix

0.014 % w/w

Temperature control range

5 ^oC - 75^oC

Temperature control accuracy (+)

0.03 ^oC

Measurement scales

Refractive Index, Sugar (Brix and more), Acid/Base, Chemical, Freezing Point, Salt, Others; Up to 30 user-defined concentration tables (can be entered as tables or formulas).

Dimensions (Width x Height x Depth)

226 x 193 x 208 mm

Weight

4.8 kg

Standard compliance

www.mt.com/dere-norms

User Management

Yes

Dimensions (HxWxD)

193 mm x 208 mm x 226 mm

Funnel for Easy Sampling

No

Product Type

Benchtop refractometer

Accuracy Brix % w/w

0.014

LIMS connectivity

Yes

Main norms and standards

AOAC 969.18; AOAC 943.05; OIV MA-AS2-02; UOP 816; AOAC 932.14, Section C; ICUMSA SPS-3 (2000); ASTM D3321; Ph. Eur. 2.2.6; AOAC 983.01; AOAC 948.10; AOAC 945.102; AOAC 969.38; ASTM D4095; ASTM D1747; DIN 51423 - part 1; AOAC 905.01; AOAC 976.20; AOAC 920.141; AOAC 896.02; AOAC 898.02; ASTM D5006; AOAC 950.13; ISO 280; GBT 10786-2006; USP 831; AOAC 921.08; AOAC 970.15; AOAC 970.59; ASTM D2140; AOAC 920.78; ASTM D4542; ASTM D 1807; A.O.C.S. Official method Cc7-25; OIML R 108; ISO 8036; AOAC 983.17; OIV MA-AS312-01B; AOAC 953.16; AOAC 2000.19; AOAC 950.04; AOAC 940.09; AOAC 932.12; ASTM D524; GB/T 12143-2008; ICUMSA GS4/3 - 13 (2004); ISI 06-1e; ASTM D1218

Compliance / Data Security

Audit Trail (requires LabX software); Data integrity (requires LabX software); 21 CFR part 11 / EU Annex 11 (requires LabX software)

Built-in Measurement Scales

Others; Chemicals, acids, bases and freezing point tables; Refractive Index

Material Number(s)

30474906
